Making a Custom Brio Compatible South West Trains Class 444 Desiro

This is a writeup of how I made a custom toy South West Trains class 444 for my 2 year old niece. Or at least, a writeup of the bits I can remember.

The first thing I did was lookup a photo of the relevant train (google images) and doodle a sort of caricature of it onto a post-it note one lunchtime at work. The gist was to simplify the look so that it would look reminiscent of the real thing but sufficiently “toy like” that it doesn’t look over detailed and fussy on a model only 11cm long.

For example – 10 windows becomes 4, or even 3 on the driving ends, the driver’s door vanishes, as do the corridor’s between coaches and lots of little outline details etc etc.

My Custom Brio style toy SouthWest Trains Desiro Class 444

I formulated a plan to find an existing Brio compatible train, cannibalize the wheels and bogies, knock up a new wooden body, and join it all back together. Then I discovered that BigJigs sell a wagon that is simply a rectangular block already.

BigJigs Wagon, unmodifed and modified. With Gordon for scale!

I bought six of these, sanded off all the paint, unscrewed the bogies and wheels, and sprayed them with a toy-safe aerosol white primer/undercoat. I then carved the ends into a simple approximation of the driving ends of the class 444 trains.

Carving a wooden toy train

Next I learnt how to use Inkscape (this was actually a bit of a joy to learn and use) and drew up a design as an SVG. I drew the side view first, which I then extended to span the roof and opposite side. The full drawings are available to download from bitbucket here. They’re free for your own use, legal bit follows:

This work is licensed under the Creative Commons Attribution-NonCommercial-ShareAlike 4.0 International License. To view a copy of this license, visit

The simplified side-only view is shown below.

My Custom Brio style toy SouthWest Trains Desiro Class 444

The first attempt at getting the design from computer to toy was not successful. I read that you can use iron-on inkjet t-shirt transfers on wood. The short answer is you can’t. The longer answer is that when you heat it with an iron, the transfer melts and becomes very slimy and slippy, at which point it slips and smears all over the place. Your mileage may vary, but I gave up.

The second plan was to try getting some inkjet water-transfer paper. But because I was up against a deadline (Christmas) I ran out of time to order some off the internet. I’d still like to try this, but at the time I fell through to plan C.

My final attempt was simply to print the design out on paper, and glue it onto the model. I painted the ends black and yellow by hand. The end result actually looks OK. I then lacquered the whole thing with a toy-safe semi-gloss aerosol varnish/lacquer. When it was all dry, I simply screwed the bogies back on (making sure to check the magnetic couplings were in north/south matched pairs, and that the two driving cabs had the opposite polarity, so they would join together) and I was done.

A quick note on toy safety. There are lots of European standards on things like toxicity of paints, and more importantly – small parts that could be a choking hazard. This model probably doesn’t meet them, and you should treat these as novelty/models not toys for tiny children (at least not children so tiny that they still chew on everything they see). For toy safe paint and Varnish, check out the Painter’s craft range from Rust-Oleum (check the label to make sure, as not all Rust-Oleum products are safe). Or look for any paint that conforms to the EN-71 standard.

And that is how I arrived at the final result. Let me know if you like it, or if you try it for yourself. My Custom Brio style toy SouthWest Trains Desiro Class 444


AngularJS Pipe in Expression Is a Filter Not Bitwise Or

If you come across a pipe (or bar) symbol in an angularJS expression, and don’t know what it means, it’s a Filter (effectively formatting options).

I had remarkable trouble googling for this problem, hence this keyword laden post. Basically if you come across a single pipe (or bar) symbol inside double curly brackets then you might think that this is a mistyped OR symbol, or if you’re a bit more JS savvy, a bitwise shift operator. In fact you have to remember that angular expressions are not vanilla javascript – they are parsed by angular itself and have their own syntax. The single pipe is in fact a filter operator which slightly confusingly is often used to format numbers, for example with localised decimal seperators.

I had to go on quite a google treasure hunt to find that out, so hopefully this can act as a bit of a signpost for the curious in future.


Custom Brio SouthWest Trains Class 444 Toy Train

My Brother is a bit of a train geek, a few years ago I made him a tiny railway as a Christmas present.

So this year I’ve made him and my 2 year old niece a joint Christmas present of a custom, one of a kind Brio style train, which is an accurate (ish) caricature of a SouthWest trains class 444 Desiro. These little wooden trains are awesome, I’ve never met a toddler who didn’t like them. There are a bunch of different manufacturers, of which Brio is just the most famous.

Some of the models are just generic “toy trains” but others are models of real trains past and present, but they’re mostly based on either German and American trains. So I made some that look like the trains you can see at my brother’s local station in Petersfield, specifically, a SouthWest Trains Class 444.

Here’s the end result: My Custom Brio style toy SouthWest Trains Desiro Class 444

Full details of how I built it, and the designs for the sides and top to follow in another blog post (if I get around to it).

I got around to it! I’ve written up how I made the trains in another blog post.


Babylon JS Experiment

Very quickly – I’ve been playing with Babylon JS to do some WebGL animations. I’ve got a scene to draw but am having trouble with animations. Here are the results so far:

Spiky BabylonJS experiment

You can fly around with the cursor keys and mouse (Babylon default behaviour). Then hit the ‘a’ key to trigger an animation (and an error – after which you can’t fly around any more!) [Edit – fixed thanks to the peeps over at the HTML5 game devs forum]

The whole reason I wanted to do this was for fun, and to try and provide a visualisation for this 3d dogfight Code puzzle, but someone beat me to it, so now it’s just for fun.


Chronhorama Project Idea

I suffer from a surfeit of ideas and not enough time and willpower to get them all finished (coughany finished). Most never leave the confines of my head. I’ve mulled over giving a lightning talk called “Ideas I’ve had but will never get round to”, so that if anyone else thought they were good ideas, maybe they could implement it.

I thought I ought to tell people about them. So here’s one of them:

Introducing Chronhorama

From the Greek: Chronos (time) and horan/horama (see/view). (Name only recently made up and liable to change at any moment)

The gist of it is: a sort of time traveling google streetview of my own garden.


I’m currently working on a bit of hardware (because that’s fun). A motorised turntable, controlled by an Arduino, that can position a camera quickly and consistently. The x-axis turntable is almost ready to be sent away for laser cutting. The Y axis is going to be phase two and will be a bit trickier. It’, still in the mulling-over phase. My progress so far is now public and open source on bitbucket.

Phase three will be to get a raspberry pi to control both the turntable (via the Arduino) and the camera (via usb) to take a whole panorama automatically. Coincidentally, the same setup could probably serve as a gigapixel rig or a time-lapse setup.

Finally, once I’ve got a few panoramas, I plan to shove it all up on a website so you can pan and scroll around a virtual view of my garden (or anywhere else). The nifty thing is, there will also be a control to travel back in time to see the same panorama on a previous date.


I’ve got a new garden I don’t know very well and I often find myself trying to remember what was growing in a spot months earlier so that I know if I’m about to hide/enhance/kill it. If I can take seasonal panoramas, I can simply refer back to the website and see that nondiscript bush (A) was covered in flowers last summer, while non-descript bush (B) is a sucker that can get hacked, hoicked and composted with appropriate malice.

Yeah, but…Why? It all seems a bit overcomplicated.

I’m not re-inventing the wheel, I’m merely re-implementing it. How else do you learn to be a wheelwright?

More accurately, it’s fun, it’s blog fodder and I want to.


QCAD Unity Launcher in Ubuntu

I recently tweeted that QCAD is all the CAD I want. I only need 2D, it’s keyboard friendly, cross platform and the default file format is DXF, which is compatible with everything and text based so git likes it (although I wouldn’t want to diff/merge one).

Anyway, it doesn’t come with a .desktop file for unity/ubuntu, so I knocked one up, which I published as a Github gist.

QCAD desktop file gist

By default, qcad is installed by just unpacking into /opt/qcad[…]/ and run from the command line. If you drop the desktop file into either /usr/share/applications/ (for all users) or ~/.local/share/applications for the current user (create the folder if it doesn’t exist). You should then be able to find the icon/launcher in unity, and be able to pin it to the sidebar if you wish.


Ubuntu 13.10 Cisco vs Openconnect Vpn

I couldn’t connect to my client’s vpn from Ubuntu 13.10 using openconnect (the open source cisco compatible vpn client that integrates nicely with Ubuntu). This seems to be a known problem in 13.10 and AFAIK shouldn’t affect 13.04 or older (certainly, it works on a colleague’s 12.04 box)

So instead I went with cisco’s own anyconnect client and it seemed to work fine. First, just browse to the vpn address in a browser. Ours is something like:


If you have java enabled in browser the client should download, if not (like me) wait for it to time out and you’ll be presented with a link to a shell script which installs the cisco vpn client. Give the script execute permissions and run it with sudo*

  chmod +x

Then I simply found the cisco anyconnect client in the launcher, type in the vpn url (without the https scheme), username and password in the box, hit connect, and it seemed to work fine.

Edit: I’ve since found some links to uninstall instructions on ubuntu forums and cisco’s site, the gist of which is, run another shell script:

  sudo /opt/cisco/vpn/bin/

*As this came from inside my trusted client’s domain behind valid ssl I assumed it was safe. On your own head be it if you go running random shell scripts on your machine as root and you end up getting a new mortgage in downtown Vladivostok.


Java Diagnose File Not Found Exceptions

Having trouble figuring out those pesky file not found exceptions? Usually it’s some relative path to a test resource file from a mystery working directory somewhere on a test slave (or in my case, a completely sensible path on my local machine that I’d mis-read). Well, the answer is so obvious I’m forcing myself to write it down as pennance for not thinking of it years ago.

FileInputStream inputStream;
try {
    inputStream = new FileInputStream(someFile);
} catch (FileNotFoundException exception){
    //Logging to debug or trace here would be more sensible, especially in live code.
    throw exception;

If the file isn’t found the full path is barfed out so you can figure out where you’re going wrong. No more randomly adding “../” into paths. I really wish something like this happened out of the box, but I guess you’d be leaking a lot of internal system info by default.


Changing Sublime Text Font Settings in Ubuntu

tl:dr – use sudo to launch sublime before changing settings (or they won’t persist).

In addition to using sudo, you need to edit the font preferences in the user’s preferences as opposed to default preferences (apparently the platform prefereces override the setting, and are between default and user in the heirarchy, but not listed in the menu for some reason).

I copied the font size property from the general preferences, and pasted it into the user prefs, which looks something like:

    "font_size": 14

Feel free to comment if I’ve misunderstood this :)

PS – the same seems to be true of entering your license key – make sure you start sublime using sudo, or it wont persist.
